Enclosure Type

Rack-mountable - 1U

Connectivity Technology

Wired

Data Link Protocol

Gigabit Ethernet

Performance

IPsec throughput (1400Bytes, clear text): 1 Gbps ¦ SD-WAN IPsec throughput (IMIX, clear text): 900 Mbps ¦ IPv4 forwarding throughput (1400-byte packet size): 6 Gbps

Capacity

SD-WAN overlay tunnels scale: 4000 ¦ IPsec SVTI tunnels: 4000 ¦ Access Control Entries (ACEs) per system (IPv4): 72000 ¦ IPv4 routes: 1600000 ¦ IPv6 routes: 1500000 ¦ Queues: 16000 ¦ NAT sessions: 1200000 ¦ Firewall sessions: 512000 ¦ Virtual Routing and Forwarding (VRF) entries: 4000

Network / Transport Protocol

RSVP, NTP, IPSec, PPPoE, DHCP, DNS, L2TPv3, RTCP

Routing Protocol

OSPF, RIP, IS-IS, RIP-2, BGP, EIGRP, HSRP, DVMRP, VRRP, IGMPv3, GRE, OSPFv3, policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD)

Remote Management Protocol

SNMP, SCP, OMP

Encryption Algorithm

DES, Triple DES, MD5, IKE, TLS, SHA-1, PKI, 128-bit AES, SHA-2, 1024-bit RSA, 2048-bit RSA, 256-bit SHA, 256-bit AES-GCM, 256-bit AES-CBC, 512-bit SHA, ESP, 748-bit RSA, 384-bit SHA, ECDSA 256-bit, ECDSA 384-bit, HMAC

Authentication Method

Secure Shell (SSH), RADIUS

Features

NAT support, PAT support, Syslog support, URL filtering, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Access Control List (ACL) support, Quality of Service (QoS), DHCP server, Bidirectional Forwarding Detection (BFD), DHCP client, Forward Error Correction (FEC), Class of Service (CoS), Call Admission Control (CAC), Flexible NetFlow (FNF), Application Visibility and Control (AVC), Source-Specific Multicast (SSM), Authentication, Authorization and Accounting (AAA), Hierarchical Quality of Service (HQoS), Encapsulated Remote SPAN (ERSPAN), Embedded Event Manager (EEM), Protocol Independent Multicast (PIM), Ethernet Virtual Connections (EVC), Cisco IOS IP Service-Level Agreements (IPSLA), Network-Based Application Recognition (NBAR), Datagram Transport Layer Security (DTLS), Point-to-Point Protocol (PPP), High-Level Data Link Control (HDLC), Multilink Point-to-Point Protocol (MLPPP), Multilink Frame Relay (MLFR), Application Aware Routing (AAR), Interactive Voice Response (IVR), Service Advertisement Framework (SAF), Secure Unique Device Identification (SUDI)

Compliant Standards

IEEE 802.1Q, IEEE 802.3ah, IEEE 802.1ag, EN 61000-3-2, IEC 61000-3-2, EN55024, EN 61000-6-1, AS/NZS 60950-1, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, FDA, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 300 386, KN35, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, AS/NZS CISPR 32 Class A, KN32 Class A, IEC/EN 61000-4-11, IEC/EN 61000-4-2, EN 55032, CISPR 32 Class A, VCCI-CISPR 32:2016 Class A, EN 55035, IEC/EN 61000-3-3, IEC/EN 60825, CAN/CSA C22.2 No. 60950-1

Processor

Intel

RAM

8 GB (installed) / 32 GB (max)

Flash Memory

8 GB

Hard Drive

16 GB

VoIP Protocols

SRTP

Interfaces

WAN: 4 x Ethernet 1000

Expansion Slots

1 (total) / 1 (free) x NIM ¦ 1 (total) / 1 (free) x Pluggable Interface Module (PIM)

Installed Modules Qty (Max)

0 (installed) / 2 (max)

Power Device

Internal power supply - 100 Watt

Installed Qty

1 (max)

Voltage Required

AC 120/230 V (50/60 Hz)

MTBF

692,577 hours

OS Required

Cisco IOS XE 17.4.1

Width

17.2 in

Depth

11.8 in

Height

1.7 in

Weight

10.01 lbs

Min Operating Temperature

32 °F

Max Operating Temperature

104 °F

Humidity Range Operating

5 - 85% (non-condensing)
