Width

3.9 in

Depth

1.1 in

Height

3.9 in

Weight

4.66 oz

Form Factor

Wall mountable

Connectivity Technology

Wired

Data Link Protocol

Ethernet, Fast Ethernet

Network / Transport Protocol

ARP, DHCP, RTP, RTCP

Remote Management Protocol

HTTP, HTTPS, TFTP, SSH

Status Indicators

Power, phone

Features

Syslog support, DiffServ support, IPv6 support, full duplex mode, SNTP support, Quality of Service (QoS), reset button, LLDP support, DHCP client, Type of Service (ToS), Internet Control Message Protocol (ICMP), dual image support, AES encryption, Cisco Discovery Protocol, secure boot, VLAN Tagging

Encryption Algorithm

AES

Compliant Standards

IEEE 802.1Q, IEEE 802.1p, IEEE 802.1ab (LLDP)

VoIP Protocols

SIP, RTCP, RTP, SRTP

Voice Codecs

G.711, G.729a, G.729ab, G.711u, G.711a, T.38

Telephony Interfaces

2 phone (FXS)

IP Telephony Features

Echo cancellation, comfort noise generation (CNG), voice activity detection (VAD), call forwarding, caller ID, adaptative jitter buffer, call waiting, call hold, call transfer, silence suppression

Interfaces

1 x 100Base-TX - RJ-45 ¦ 2 x FXS - RJ-11

MTBF

300,000 hours

Compliant Standards

FCC Part 15 B, EN 61000-4-2:2009, EN 61000-4-11:2004, EN 61000-3-3:2013, EN 61000-4-3:2006+A1:2008+A2:2010, EN 61000-4-8:2010, EN 61000-4-5:2014, EN 55024:2010+A1:2015, Directive 2014/35/EU, Directive 2014/30/EU, EN 61000-4.4:2012, UL 60950 Second Edition, CAN/CSA C22.2 No. 60950 Second Edition, ANSI C63.4-2014, AS/NZS 60950-1:2015, EN 61000-3-2:2014 Class A, EN 55032:2015 Class B, AS/NZS CISPR32:2015 Class B, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013

Power Device

External power adapter

Voltage Required

AC 120/230 V / DC 5 V

Power Consumption Operational

5 Watt

Service & Support

Limited warranty - 1 year

Min Operating Temperature

32 °F

Max Operating Temperature

104 °F

Humidity Range Operating

10 - 90% (non-condensing)
